Orbita PC Micro Sprinkler

Flawless, Pressure-Compensating Coverage for Large Landscapes

Ensure every plant receives the exact same amount of water, regardless of its location in your garden. The Orbita PC Micro Sprinkler is a professional-grade, pressure-compensating (PC) emitter engineered for superior water distribution uniformity. Whether you are dealing with elevation changes, sloped terrain, or exceptionally long irrigation lines, the internal PC diaphragm regulates flow to maintain a constant output and throw diameter. Featuring a robust C-frame design and dual bearings that support the spinner during rotation, this micro-sprinkler is built for reliable, long-term performance. Secure them above your plants using rigid risers or 1/4″ micro tubing to create a highly efficient, zero-waste watering system for your vegetable gardens, flower beds, and large landscaped areas.

• Guaranteed Uniform Watering: The built-in pressure-compensating diaphragm ensures a consistent flow rate across a wide 20-45 PSI pressure range, solving the most common cause of uneven plant growth on slopes.
• Advanced Dual-Bearing Design: Two precision bearings fully support the spinner during operation, reducing friction and ensuring a perfectly even, long-lasting 360° spray pattern.
• Strong C-Frame Construction: The heavy-duty acetal frame provides excellent structural rigidity, ensuring the sprinkler head maintains its shape and performance even when exposed to harsh summer sun.
• Color-Coded Pre-Defined Flows: Available in easily identifiable color-coded bases so you always know exactly how much water is being applied to different zones of your landscape.

Review the exact performance metrics to choose the right Orbita PC configuration for your layout.

• Operating Pressure Range: 20 to 45 PSI (1.5 to 3.0 Bar)
• Spray Pattern: 360-Degree Full Circle
• Filtration Requirement: 120 Mesh (for Blue) | 80 Mesh (for Green/Red)
• Connection Type: Available with 10-32 Threaded Base or Barbed Base

Set up your precision watering system quickly and easily depending on your base style.

Step 1: Puncture the Mainline
Using a DripWorks key punch or pocket punch tool, create a clean hole directly in your 1/2-inch mainline poly tubing near the location you want to water.

Step 2: Insert the Support Stake and Tubing
If using the Threaded base: Twist the threads into the top of a rigid riser or compatible stake assembly (such as the Ultra Stake or EZ Stake Assembly), then connect that assembly to your mainline using the transfer barb.

Step 3: Secure Upright
For optimal performance and to achieve the full 360-degree spray radius, ensure the C-frame is standing perfectly upright. If mounted on flexible tubing, use a wire hold-down to stabilize it.

Step 4: Regulate Pressure
Ensure your head assembly has a pressure regulator installed that keeps the system within the 20 to 45 PSI operational window so the PC diaphragm can do its job.
